TALINO KA-301 Forensic Workstation

TALINO_00
TALINO_05TALINO_01TALINO_02TALINO_03TALINO_04Motherboard_01Motherboard_02Motherboard_03Motherboard_04Motherboard_05Motherboard_06Motherboard_07Motherboard_08Motherboard_09Motherboard_10Motherboard_11Motherboard_12Motherboard_13Motherboard_14Motherboard_15Motherboard_16Motherboard_17Motherboard_18Motherboard_19Motherboard_20iStarUSA_Bay_01iStarUSA_Bay_02iStarUSA_Bay_03iStarUSA_Bay_04samsung-9605_Bay_Backplane_015_Bay_Backplane_035_Bay_Backplane_02Six_Bay_1Six_Bay_3Six_Bay_4Six_Bay_2Samsung_850_Evo_Pro_5Samsung_850_Evo_Pro_1Samsung_850_Evo_Pro_2Samsung_850_Evo_Pro_3Samsung_850_Evo_Pro_4Four_Bay_3Four_Bay_4Four_Bay_2Four_Bay_1GTX_1070_WC_11GTX_1070_WC_10GTX_1070_WC_09GTX_1070_WC_08GTX_1070_WC_07GTX_1070_WC_06GTX_1070_WC_01GTX_1070_WC_02GTX_1070_WC_03GTX_1070_WC_04GTX_1070_WC_05TALINO_ComparisonM2_Carrier_0M2_Carrier_1M2_Carrier_2

TALINO KA-301 Forensic Workstation

$9,495.00

The TALINO KA-301 Forensic Workstation is our MID-LEVEL Desktop Processor system, which features superior processing power and capabilities, including an Intel Core i7-6900K, 3.7GHz 30MB Cache processor fit for overclocking, 64GB of DDR4 2400 GHz RAM, a 512GB SSD for the Operating System, a 512GB M.2 SSD for Temporary Files and Processing, a 512GB M.2 SSD for Database Files, and an 12TB RAID 10 system.  The GTX 1070 8GB GDDR5X Graphics Processing Unit provides maximum graphics processing power and less lag when trying to process graphics through forensic software.  There are Five (5) 3.5″ and Four (4) 2.5″ hard drive hot-swap bays.

The KA-301 is Far Superior in Performance and Configuration than our competitors similar systems due to the Multiple Drive Volumes to handle your most Stringent Forensic Software and the Speed of Equipment and Controllers. You will not find a Better Forensic Workstation Anywhere. All of this comes with a Three (3) Year Standard Warranty.

Online Purchases and Pricing are for the US only. For International Purchases and Support Please Contact Us.  Image represented in photograph is stock; customizations will render each system unique.

Configure Options

RAM

The KA-301 comes with 64GB of DDR4 RAM. Would you like to upgrade your RAM to increase performance?

OS DRIVE

Do you want to upgrade your Operating System drive?

TEMP/CACHE/SWAP STORAGE

Do you want to add independent storage for TEMP/CACHE/SWAP files which increase the performance of your forensic tools?

QUAD M.2 CARRIER

With the addition of this Quad M.2 Carrier you can add up to 8TB of M.2 Storage to your System. This card adds blazingly fast speeds at 3500 MB/s Read & 2100 MB/s Write.

DATABASE Storage

Would you like to increase the size of the Cases and Database(s) Storage?

EVIDENCE/DATA STORAGE

Do you want to add independent storage for EVIDENCE/DATA files which increase the performance of your forensic tools?

WRITE BLOCK

The TALINO Forensic Workstations comes with the Tableau T-3iu Forensic Bridge which will write-block all 2.5″ and 3.5″ hard disk drives and SSDs. Would you like to add additional equipment?

KEYBOARD AND MOUSE

Would you like to add a keyboard and/or mouse?

MONITOR

Would you like to add a monitor?

OPERATING SYSTEM

By Default we Install Windows 10 Professional 64 bit. Would you like this Operating System Installed or one of the following? (NOTE: The latest version of EnCase is NOT Certified to run with Windows 10. We Strongly Suggest Windows 7 Professional 64 Bit if EnCase is your Primary Forensic Utility)

MAC FORENSIC SOFTWARE

Would You Like to Add Forensic Software?

ADDITIONAL FORENSIC SOFTWARE

Would you like to add additional Forensic Sotware

Categories: , , ,

Product Description

  • Intel Core i7-6900K Broadwell-E 8-Core 3.2GHz LGA 2011-v3 Desktop Processor
  • 64GB of High End 2400 MHz Ultra Fast DDR4 RAM
  • One (1) 512GB SSD for the Operating System
  • One (1) 512GB M.2 SSD for Temporary Files and Processing
  • One (1) 512GB M.2 SSD for Database(s)
  • Four (4) 6TB Hard Drives Configured in RAID 10 for Evidence
  • One (1) GTX 1070 8GB GDDR5 Water Cooled Graphics Processing Unit
  • One (1) 2.5” Hot Swap Bay with Four (4) Hot Swap Bays
  • One (1) 3.5” Hot Swap Trays totaling Five (5) Removable Trays
  • One (1) Blu-Ray16X BD-R 4MB Cache SATA Blu-ray Burner
  • Liquid Cooling for the CPU Providing Maximum CPU Performance
  • Forensic Card Reader as Front Panel
  • One (1) 7 Port USB 3.0 Hub
  • One (1) 10 Port USB 2.0 Hub
  • Tableau T-3iu Installed
  • One (1) 1200 Watt Power Supply Unit
  • High End Whisper Quite Fans throughout the Entire System (Hydraulic Fluid Ball Bearing rated at 300,000 hour lifespan
  • Microsoft Windows 10 Pro 64 Bit
  • Three (3) Year Standard Warranty
  • Additional Specifications
    • Size: 15″W x 19.06″H x 20.06″D (381mm x 484mm x 510mm)
    • Open 5.25″ Bays = 10
    • Fan size(s) = 120mm
    • PCI Chassis Expansion Slots = 8
    • Aluminum Thickness = 0.080″ (or 2.032mm)
    • Finish = Powder Coated Black with Black Appointments
